GPS Antennas Specifications

Category
Frequency Range
Impedance
VSWR
Gain
LNA Current Consumption
Noise Figure
Polarization
Input voltage

Bluetooth and Wi-Fi Antennas

Manufacturer:
Manufacturer's Model Number:
Multi-Tech Systems:

Multi-Tech Ordering Information

Model Number
ANWF-1HRA
ANWF-10HRA
ANWF-50HRA

Antenna Specifications

Category
Frequency Range
Impedance
VSWR
Peak Radiated Gain
Radiation
Polarization
Connector
®
MultiConnect rCell 100 MTR-H5 User Guide
Description
1575.24 MHz
50 Ohms
2.0:1 max
10-30 dBi
40 mA max
< 2dB
RHCP
3.0V ± 0.2V
Taoglas Antenna Solutions
GW.11.A153
45009740L
Quantity
1
10
50
Description
2.4000 to 2.4835 GHz
50 Ohms
VSWR should not exceed 2.0:1 at any point across the bands of operation
2.3 dBi on azimuth plane
Omni-directional
Linear Vertical
RP-SMA(M)
CHAPTER 3 CELLULAR INFORMATION
