Setting up Caller Acknowledgement
1. In the group, in the field, type a configured string (0 to 40 characters) that is sent to the integrated
cellular modem upon receiving a valid SMS from the WAN.
2. Set the Wakeup Acknowledgement string configuration with the command AT+CNMA.
3. To save the Acknowledgement Configuration click Submit.
After you finish making your changes, you must save and restart. The device saves all the settings and reboots.
Using Telnet to communicate with the cellular radio
Your router comes with an integrated cellular radio. You can use this cellular radio directly without using any
router functions. To do so, you must use redirector software on your computer. This software creates a virtual
serial port that allows your computer to communicate with the integrated cellular radio over IP using telnet.
To communicate directly with the cellular modem:
1. From Cellular, select Telnet Radio Access.
2. In the pane that appears, check Enabled.
3. To enable raw mode, check Raw. The program transfers data between the computer and cellular
modem without any processing.
4. To enable the Auto Dialout Login feature, check Login. The Auto Dialout port is the Telnet port used by
the redirector software on your computer to communicate to the cellular modem integrated on the
router.
5. In the Port field, type the serial Auto Dialout Port number. The default is 5000.
6. In the Inactivity field, type the time in seconds that the auto dialout session remains active before
becoming inactive.
7. To enable the EIA standard signal characteristics (time and duration) used between different electronic
devices, check Handle EIA Signal.
