a. From the Encryption drop-down list, select the encryption to be used.
b. To generate a key from a phrase, in the Passphrase field, type a phrase. Click Generate.
c. To manually enter keys, type the keys in the Key 1, Key 2, Key 3 or Key 4 fields.
3. To configure WPA-PSK and WPA2-PSK:
a. Select the WPA Algorithm from the drop-down list.
b. In the Shared Key field, type the key that is used for encrypting and decrypting the data.
c. To remove the mask characters, thereby making the Shared Key visible, check Unmask.
4. When done, click Submit, then Save and Restart.

Viewing information about Wi-Fi clients using your wireless network

To view information about clients (such as computers, tablets, and smart phones) that are connected to your
router's Wi-Fi access point:
1. The Clients group displays a list of clients using your router's WiFi.
2. To update the list, click Refresh.

Setting Up Wi-Fi as WAN

To setup the router's WiFi as WAN:
1. Go to Wireless > Wi-Fi to display the Wi-Fi window.
2. From the Wi-Fi Mode drop down list, select Wi-Fi as WAN.
3. Searching for available Wi-Fi networks starts automatically. After 30 to 60 seconds, a list of detected Wi-
Fi Access Points appears in the Available Networks group.
4. In the Available Wi-Fi Networks group, click the SSID for the Wi-Fi access point you want to use. The Add
Saved Network window opens.
5. Review the information, enter any required security info, then click Finish. The Wi-Fi access point you just
added appears in the Saved Wi-Fi Networks group.
6. If desired, add additional access points to the list of Saved Networks. The router tries to connect to Saved
Networks in the order they are listed. You can change the order by clicking the up or down arrows shown
under Options.
7. When finished, click Save and Restart. The Status field displays "Connected" if you have successfully
connected to the Wi-Fi access point.

Setting up Bluetooth

The Bluetooth-IP feature allows a data connection between a remote TCP/UDP client or server and a local
Bluetooth device. To set up the Bluetooth connection:
1. Go to Wireless > Bluetooth
2. To enable the feature, check Enabled. Click Submit.
3. Confirm that the far-end Bluetooth device is powered on and waiting for a connection.
4. In the Available Devices group, click Refresh. A list of detected Bluetooth devices appears.
5. Click the name of the Bluetooth device that you want to use. The name and MAC address appear under
the selected device.
®
MultiConnect rCell 100 MTR-H5 User Guide
CHAPTER 7 SETTING UP WIRELESS FEATURES
39
