Configuring Wake Up On Call

This feature allows the router to wake up and initiate a cellular connection when there is an incoming call, SMS, or
LAN activity.
1. Go to Cellular > Wake Up On Call to display the configurations.
2. Check the Wake Up On Call box.
3. Select a Wake Up method.
4. Click Submit.
Note: This feature only defines when the device should bring up its cellular link, not when the device should
bring it down. See the Dial on Demand option on the Cellular Configuration page at Cellular > Cellular
Configuration to configure the criteria for bringing the cellular link down.

Wake Up On Call Settings

The triggers that establish the cellular link are:
■
On Ring:
■
Any incoming call will bring up the cellular link.
■
Enabled: Check to allow any incoming call to wake up the router.
■
Message: The expected response from the integrated cellular modem to an incoming call.
■ On Caller ID:
■ Only incoming calls in the caller ID list will bring up the cellular link.
■
Enabled: Check to allow a specific caller to wake up the router.
■
Caller ID: Field to specify a caller ID. Click Add to add the caller to the approved caller ID trigger list.
■
On SMS:
■
Only specific SMS messages will bring up the cellular link.
■ Enabled: Check to allow specific SMS messages to wake up the router.
■ Message: Field to specify the SMS message contents. Click Add to add the SMS message to the
approvede SMS trigger list.
For Wake-Up-On-Call field descriptions see Wake Up On Call General Configurations

Wake Up On Call General Configurations

Field
Wake Up on Call check box
Dial On Demand LAN
Time Delay
®
MultiConnect rCell 100 MTR-H5 User Guide
CHAPTER 9 SETTING UP CELLULAR FEATURES
Description
Enables the Wake Up On Call feature.
When checked, the router will allow network activity on
the LAN that needs WAN access to trigger the Wake Up
and establish the cellular link. If this configuration is not
checked, the router will only establish a cellular
connection when the selected Wake Up method is
triggered via incoming call, caller ID, and/or SMS.
Time that passes between receiving call and initiation
the Wake Up On Call connection.
