RUBBER BEZEL
QUARTZ HALOGEN
BULB
SMART
ELECTRONIC
DIMMER
SWITCH
12 Volt DC Charging Adapter
DC RECHARGING
PORT
TRIGGER SWITCH
LOCK
PISTOL GRIP HANDLE
CARRY
LANYARD
3/4 View
BUILT-IN
120 VOLT AC
CHARGER
Back View
2
OPERATING INSTRUCTIONS
To turn the cordless spotlight on depress the Trigger Switch. Depressing the Trigger
Switch at one-second intervals advances the brightness level from dim to brightest.
To lock the trigger into the ON position pull the Trigger Switch and move the Trigger
Switch Lock down. This will lock the trigger into the ON position. To shut it off, simply
move the Trigger Switch lock up to the OFF position.

PERIODIC MAINTENANCE

All batteries lose charge with time, especially when they are warm. AC recharge is
recommended every two months, when not in frequent use. Use the AC recharger and
charge for the recommended time. If the unit gets dirty, gently clean the outer surfaces
of the spotlight unit with a soft cloth moistened with a mild solution of water and
detergent. Periodically inspect the condition of the recharge adapters, connectors and
wires. Replace any components that may have become worn or broken.
RECHARGING THE SPOTLIGHT
Charging From a 120 Volt AC Source
To recharge, plug a 120 volt AC household extension cord into the 120 volt AC
Recharger on the back of the unit and charge for 12-14 hours or until the green
Battery Charge Level Indicator LED lights.
HOUSEHOLD EXTENSION CORD
(NOT INCLUDED)
Charging From a 12 Volt DC Source
Plug the DC fused Recharge/Power Adapter (included) into the Recharge Port.
TRIGGER SWITCH
TRIGGER SWITCH
LOCK
BATTERY CHARGE
LEVEL INDICATOR
BUILT-IN 120V AC
CHARGER
RECHARGE PORT
3
