SL102B_ManualEN_051007.qxp
V-1 MILLION POWER SERIES
Thank you for choosing Black & Decker!
Go to www.BlackandDecker.com/NewOwner
BEFORE RETURNING THIS PRODUCT
BEFORE YOU CALL, HAVE THE CATALOG No, AND DATE CODE
AVAILABLE. IN MOST CASES, A BLACK & DECKER REPRESENTATIVE
CAN RESOLVE THE PROBLEM OVER THE PHONE. IF YOU HAVE A
SUGGESTION OR COMMENT, GIVE US A CALL. YOUR FEEDBACK IS
TO REDUCE THE RISK OF INJURY, THE USER MUST READ AND
UNDERSTAND THE INSTRUCTION MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Cat. # SL102B
April '07
5/10/07
INSTRUCTION MANUAL
to register your new product
FOR ANY REASON PLEASE CALL
1-800-544-6986
VITAL TO BLACK & DECKER.
Form # 90515795
Copyright © 2007 Black & Decker
9:13 AM
Page i
SPOTLIGHT
Catalog Number SL102B
Printed in China

Advertisement

loading

  Related Manuals for Black & Decker Power Series 90515795

  Summary of Contents for Black & Decker Power Series 90515795

  • Page 1 SL102B_ManualEN_051007.qxp V-1 MILLION POWER SERIES INSTRUCTION MANUAL Thank you for choosing Black & Decker! Go to www.BlackandDecker.com/NewOwner to register your new product BEFORE RETURNING THIS PRODUCT FOR ANY REASON PLEASE CALL BEFORE YOU CALL, HAVE THE CATALOG No, AND DATE CODE AVAILABLE.
  • Page 2 SL102B_ManualEN_051007.qxp GENERAL SAFETY WARNINGS AND INSTRUCTIONS FOR ALL APPLIANCES READ ALL INSTRUCTIONS WARNING: Read all instructions before operating product. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. • AVOID DANGEROUS ENVIRONMENTS Don’t use appliances in damp or wet locations. Don’t use appliances in the rain. •...
  • Page 3: Safety Guidelines - Definitions

    SL102B_ManualEN_051007.qxp • EXTENSION CORDS. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating. The following table shows the correct size to use depending on cord length and nameplate ampere rating.
  • Page 4: Charging/Recharging The Spotlight

    SL102B_ManualEN_051007.qxp • Position charging adapter cords so they do not become entangled or become a safety hazard. Keep charging adapter cords away from sharp edges. • Use in a dry location only. • Do not open body casing. There are no user-serviceable parts inside. •...
  • Page 5: Care And Maintenance

    SL102B_ManualEN_051007.qxp Charge until the Battery Status LED Indicator red LED flashes (approximately 12-14 hours). DO NOT CHARGE FOR LONGER THAN 14 HOURS. Charging/Recharging Using the 12 Volt DC Charging Adapter Plug the barrel tip of the supplied 12 Volt DC Charging Adapter into the 12 Volt DC Charging Port. 12 VOLT DC CHARGING ADAPTER Insert the 12 volt DC plug end into the accessory outlet of your vehicle or other 12 volt DC power source.
  • Page 6 SL102B_ManualEN_051007.qxp 1. Disconnect the unit from any charging adapters. 2. Push the rubber bezel forward toward the front of the spotlight to reveal two small Phillips screws in the retaining ring. 3. Using the screwdriver, remove (counterclockwise) the two screws. Set them aside. 4.
  • Page 7: Troubleshooting

    SL102B_ManualEN_051007.qxp TROUBLESHOOTING The Battery Status Indicator LED Does Not Light When Charging 1. Check connection to the 120 Volt AC Charger or 12 Volt DC Charging Port. 2. Check connection to AC or DC power source. 3. Confirm there is a functioning AC or DC current. Unit Will Not Operate 1.
  • Page 8: Specifications

    SL102B_ManualEN_051007.qxp SPECIFICATIONS Spotlight Bulb: 6 volt, H3 series, 55 watt Battery: Maintenance-free, sealed lead acid, 6 volt, 3 amp hour AC Charger: UL Listed Class 2, 12 volt DC (300 mA) DC Plug Fuse: 0.5A/250 V Imported by Black & Decker (U.S.) Inc., 701 E.
