Table 7 Advanced Menu – Super Io Configuration - Quanmax QDSP-0200 Series User Manual

M a i n A d v a n c e d
Super IO Configuration
> Serial Port 1 Configuration
Table 8 Advanced Menu – Super IO Configuration – Serial Port 1 Configuration
M a i n A d v a n c e d
Serial Port 1 Configuration
Serial Port
Device Settings
Change Settings
Serial Port 1 Type
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;
Serial Port 1 Type
Options: RS232, RS422, RS485
