- Page 1 QDSP-400 Series Mini Digital Signage Player ® with Intel Skylake / Kaby Lake U-Series Processors User’s Guide...
-
Page 2: Table Of Contents
Chapter 3 AMI BIOS Setup ..................24 Overview ..................... 24 Main Menu ..................25 Advanced Menu .................. 26 Power Menu ..................33 Boot Menu ..................34 Security Menu ..................35 Save & Exit Menu ................36 Chapter 4 Driver Installation ..................38 QDSP-400 Series User’s Manual... -
Page 3: Figures & Tables
Table 9 Advanced Menu – USB Configuration ........... 31 Table 10 Advanced Menu – H/W Monitor ........... 32 Table 11 Power Menu................. 33 Table 12 Boot Menu ................... 34 Table 13 Security Menu ................35 Table 14 Save & Exit Menu ................ 36 QDSP-400 Series User’s Manual... -
Page 4: Safety Instructions
Turn off system power, turn off the power supply, and then disconnect the power cord from its source before removing the chassis cover. Turning off the system power switch does not remove power to components. QDSP-400 Series User’s Manual... -
Page 5: When Working Inside A Computer
ESD procedure, which can include wrist straps and smocks, when servicing equipment. You can also take the following steps to prevent damage from electrostatic discharge (ESD): When unpacking a static-sensitive component from its shipping carton, do not QDSP-400 Series User’s Manual... -
Page 6: Instructions For Lithium Battery
(e.g. to the collecting points for disposal of batteries) Voltage Ratings The external power adaptor of the QDSP-400 Series has the following voltage ratings: Input: 100~240 VAC, 50~60 Hz ... -
Page 7: Preface
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the QDSP-400 Series User’s Manual... -
Page 8: Maintaining Your Computer
However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an acceptable range. Refer to the “Specifications” section of this user’s guide for QDSP-400 Series User’s Manual... - Page 9 UPS system. UPS systems range in price from a few hundred dollars to several thousand dollars, with the more expensive unit s allowing you to run larger systems for a QDSP-400 Series User’s Manual...
- Page 10 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. QDSP-400 Series User’s Manual...
-
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Overview QDSP-400 Series is a Box PC enclosed within a palm-sized aluminum chassis. Powered by Intel® Skylake / Kaby Lake U-Series processors, it delivers excellent processing and graphics performance to applications requiring intense data throughput, especially for video / image data. -
Page 12: Product Specifications
Operation Temp.: 0 °C ~ 50 °C / 32 °F ~ 122 °F Environmental Storage Temp.: -20 °C ~ 80 °C / -4 °F ~ 176 °F Characteristics Humidity: 0 % ~ 90 % Mounting VESA mount Certifications CE, FCC Class A Table 1 Product Specifications QDSP-400 Series User’s Manual... -
Page 13: System Tour
The Wireless LED will light when the Wi-Fi is on. Storage LED The storage LED blinks when data is being written into or read from the SSD. Power Button The power button allows powering ON and OFF the system. (with Power LED). QDSP-400 Series User’s Manual... - Page 14 Chapter 1 IR Receiver The IR receiver is an infrared receiving sensor allowing users to remotely control the box PC itself or the content that is displayed on connected screens. QDSP-400 Series User’s Manual...
-
Page 15: Figure 2 Rear Panel
HDMI connector for display output. DP is a display interface used to connect a video source to a display device such as a computer monitor or a television set. D-Sub 9 pin connector for RS-232/422/485 connection. QDSP-400 Series User’s Manual... - Page 16 Spared hole on the casing for connecting Wi-Fi or 3G / 4G external antenna. Clear CMOS 1x reset button for clear CMOS. External Power Button The external power button allows powering ON and OFF the system. QDSP-400 Series User’s Manual...
-
Page 17: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 130 x 111 x 35 mm (W x D x H) Figure 3 Mechanical Dimensions QDSP-400 Series User’s Manual... -
Page 18: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your PC Connecting the monitor Connect the HDMI / DP cable from your display to the HDMI / DP port. HDMI Figure 4 HDMI / DP QDSP-400 Series User’s Manual... -
Page 19: Figure 5 Connecting Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your QDSP-400 Series does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. USB 3.0 Figure 5 Connecting USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 20: Figure 6 Rj45 Connector
Connecting to a network device Connect one end of a network cable to the LAN port on the system rear panel and the other end to a hub or switch. RJ45 Figure 6 RJ45 connector QDSP-400 Series User’s Manual... -
Page 21: Figure 7 Turning On The System
Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system DC Jack / 2-pin Phoenix Connector On / Off Figure 7 Turning on the system QDSP-400 Series User’s Manual... -
Page 22: Mounting Your Pc To A Monitor
To fasten the metal shelf, your monitor must comply with VESA75 or VESA100 standard. The VESA mounting kit is optional. Place the QDSP-400 Series on the VESA mounting bracket and make sure the bracket is hooked with the fins of the system housing. -
Page 23: Anti-Theft Protection With A Kensington Lock
Chapter 2 Anti-theft protection with a Kensington Lock QDSP-400 Series has a Kensington lock slot for the Kensington MicroSaver. With the Kensington MicroSaver, a sturdy steel cable, you can attach your QDSP-400 Series to a stationary object and protect your PC from theft. -
Page 24: Chapter 3 Ami Bios Setup
It is possible for the CMOS battery to fail, which will cause data loss in the CMOS only. If this happens you will need to reconfigure your BIOS settings. QDSP-400 Series User’s Manual... -
Page 25: Main Menu
ESC: Exit Microcode Revision Processor Cores 2Core(s) / 4Thread(s) Memory Information Total Size 4096 MB (DDR4) Frequency 2133 MHz System Date [Fri 01/01/2016] System Time [00:21:45] Access Level Administrator Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. QDSP-400 Series User’s Manual... -
Page 26: Advanced Menu
> SATA Configuration ESC: Exit > USB Configuration > H/W Monitor Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled QDSP-400 Series User’s Manual... -
Page 27: Table 4 Advanced Menu – Display Configuration
Options: 0M, 32M, 64M, 4M, 8MB, 12M, 16M, 20M, 24MB, 28M, 32M/F7, 36M, 40M, 44M, 48M, 52M, 56M, 60M DVMT Total Gfx Mem Options: 128M, 256M, MAX Primary IGFX Boot Display Options: VBIOS Default, DP, HDMI QDSP-400 Series User’s Manual... -
Page 28: Table 5 Advanced Menu – Super Io Configuration
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port 1 Type Options: RS232, RS422, RS485 RS485 Duplex Mode [Half Duplex] Options: Half Duplex, Full Duplex RS485 Auto Flow Control [Disabled] Options: Disabled, Enabled QDSP-400 Series User’s Manual... -
Page 29: Table 7 Advanced Menu – Cpu Chipset Configuration
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. EIST Options: Disabled, Enabled Turbo Mode Options: Disabled, Enabled Hyper-Threading Options: Disabled, Enabled VT-d Options: Disabled, Enabled Active Processor Cores Options: All, 1 Intel (VMX) Virtualization Technology Options: Disabled, Enabled QDSP-400 Series User’s Manual... -
Page 30: Table 8 Advanced Menu – Sata Configuration
Port 1 [Enabled] Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. SATA Controller(s) Options: Enabled, Disabled SATA Mode Selection Options: AHCI, Intel RST Premium Serial ATA Port 1 Options: Disabled, Enabled mSATA Port 1 Options: Disabled, Enabled QDSP-400 Series User’s Manual... -
Page 31: Table 9 Advanced Menu – Usb Configuration
F4: Save & Reset USB Mass Storage Driver Support [Enabled] ESC: Exit Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. Legacy USB Support Options: Disabled, Enabled XHCI Hand-off Options: Enabled, Disabled USB Mass Storage Driver Support Options: Disabled, Enabled QDSP-400 Series User’s Manual... -
Page 32: Table 10 Advanced Menu – H/W Monitor
: +3.344 V +3VSB : +3.360 V +VBAT : +3.120 V +5VA : +5.064 V +3VA : +3.296 V Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. Smart FAN Configuration CPU FAN Setting [Manual] Options: Manual, Smart QDSP-400 Series User’s Manual... -
Page 33: Power Menu
Resume By LAN Device Options: Disabled, Enabled Resume By PCI-E Device Options: Disabled, Enabled Resume By Ring Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled WatchDog Timer Configuration WDT Function [Disabled] ■ Options: Disabled, Enabled QDSP-400 Series User’s Manual... -
Page 34: Boot Menu
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. Full Screen LOGO Display Options: Disabled, Enabled Bootup Numlock State Options: On, Off CSM Support Options: Enabled, Disabled Boot Option Filter Options: UEFI and Legacy, Legacy only, UEFI only QDSP-400 Series User’s Manual... -
Page 35: Security Menu
Setup. In Setup the User will have F4: Save & Reset Administrator rights ESC: Exit The password length must be in the following range: Minimum Length Maximum length Administrator Password User Password Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. QDSP-400 Series User’s Manual... -
Page 36: Save & Exit Menu
Enter: Select +/-: Change Opt. Save Options F1: General Help Save Changes F2: Previous Values F3: Optimized Defaults Discard Changes F4: Save & Reset Restore Defaults ESC: Exit Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc. QDSP-400 Series User’s Manual... - Page 37 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. QDSP-400 Series User’s Manual...
-
Page 38: Chapter 4 Driver Installation
You can download the drivers for the QDSP-400 Series from our website and install as instructed there. For other operating systems, please contact us.
