. Attachment

Attach the connector of the speaker-microphone into the [SP MIC]
connector on the transceiver and tighten the screw with a coin or
flat head screwdriver.
IMPORTANT: KEEP the [SP MIC] jack cover attached (trans-
ceiver) when the speaker-microphone is not in use. Water will
not get into the transceiver even if the cover is not attached,
however, the terminals (pins) will become rusty, or the trans-
ceiver will function abnormally if the connector gets wet.

SPEAKER-MICROPHONE

CAUTION:
multi connector snugly, but
do not overtighten.
A loose connection will al-
low water intrusion into the
connector; an overtight-
ened connector will dam-
age the connector pins in
the transceiver.
Coin
Screw
6
Attach the
