Position Data Transmission - Icom IC-F60 Instruction Manual

4
BIIS OPERATION

. Position data transmission

When the optional OPC-966
is connected to the transceiver, the position (longitude and lati-
tude) data can be transmitted automatically.
Ask your dealer or system operator for connection details.
The position data is transmitted when;
• Status 24 message is received
*When the status 24 message, GPS request, is received.
• Fully automatic
When automatic position transmission is enabled, send the
position data according to 'Time Marker' and 'Interval Timer'
settings.
• PTT is released
When 'Send with Logoff' is enabled.
- Set the "Log-In/Off" item as "L-OFF".
• After sending a status message
When 'Send with Status' is enabled.
• After sending an SDM
When 'Send with SDM' is enabled.
• After sending status 22 (Emergency)
When 'Send with Emergency' is enabled.
31
interface cable
and a GPS receiver
