Icom IC-F60 Instruction Manual page 47

D AD-100 installation
The AD-100
charger adapter
or BC-121N before battery charging.
➥ Connect the AD-100
121N as below, then install the AD-100 into the holder space of
the BC-119N or BC-121N with the supplied screws.
Desktop charger adapter
Plugs
must be installed into the BC-119N
charger adapter
* This illustration is described with the BC-119N.
BATTERY CHARGING
and the BC-119N/BC-
Connectors
Screws supplied
with the charger
adapter
5
5
40
