6.7 RS-232 and Telnet Commands

COMMAND
A1~A8
B1~B8
C1~C8
D1~D8
E1~E8
F1~F8
G1~G8
H1~H8
ABCD...1~ABCD...8
SETIP <IP> <SubNet> <GW>
RSTIP
IPCONFIG
P0
P1
I1~I8
ST
RS
EM
?
QUIT
7
DESCRIPTION
Switch Output A to 1~8
Switch Output B to 1~8
Switch Output C to 1~8
Switch Output D to 1~8
Switch Output E to 1~8
Switch Output F to 1~8
Switch Output G to 1~8
Switch Output H to 1~8
Switch Output ABCD... to 1~8 at the
same time
Setting IP. SubNet. GateWay<Static IP>
IP configuration was reset to factory
defaults<DHCP>
Display the current IP config
Power Off
Power On
Switch all the output to 1~8
Display the current matrix state and
firmware version
System Reset to H8
Setting EDID MODE. 1-STD 2-TV.
Display all available commands
Exit (Telnet only)
