Summary of Contents for CYP nT15GX01
- Page 1 SOLUTIONS FOR GROWTH n - TECH SOLUTIONS nT15GX01 | CMSI-8D8DSA 8×8 DVI Matrix with Audio Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of re, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........4 6.3 Side Panel .........5 6.4 Remote Control ........5 6.5 RS-232 Pin Assignment .....6 6.6 RS-232 and Telnet Commands ..7... -
Page 6: Introduction
1. INTRODUCTION The 8×8 DVI Matrix with Audio is the perfect choice for the switching and distribution of DVI sources. Connect up to eight DVI sources to eight DVI displays allowing any source to be independently displayed on any monitor. Each DVI input and output has a corresponding 3.5mm mini-jack connection allowing for audio to be distributed. -
Page 7: Features
5. FEATURES • HDMI, HDCP 1.1 and DVI compliant • Supports HDMI 3D feature (with HDMI to DVI adaptor cable) • Supports resolutions to VGA ~ WUXGA and 480i~1080p dependent upon the output display's EDID settings • Supports stereo audio input and output via 3.5mm mini-jack cable •... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel MENU POWER LOCK 8X8 DVI MATRIX CMSI-8D8DSA LCM: Displays the setting information of each input and output setting. POWER: Press this button to power the device on/off. The LED will illuminate green when the power is on, red when it is in 'Standby' mode. -
Page 9: Rear Panel
6.2 Rear Panel DVI OUT DC 24V DVI IN CONTROL: This port is the link for Telnet and Web GUI controls, connect to an active Ethernet link with an RJ45 terminated cable (for further details, please refer to section 6.7 & 6.8). RS-232: Connect to a PC or control system with D-Sub 9-pin cable for the transmission of RS-232 commands. -
Page 10: Side Panel
6.3 Side Panel Fan Ventilator: These are air ventilation areas, DO NOT block these areas or cover it with any object. Please allow adequate space around the unit for air circulation. 6.4 Remote Control POWER ; Press this button to switch on the device or set it to standby mode. -
Page 11: Rs-232 Pin Assignment
6.5 RS-232 Pin Assignment CMSI-8D8DSA Remote Control Console Assignment Assignment ► ◄ Baud Rate: 19200 bps Data Bit: 8-bit Parity: None Flow Control: None Stop Bit: 1-bit... -
Page 12: Rs-232 And Telnet Commands
6.6 RS-232 and Telnet Commands Command Description A1~A8 Switch Output A to 1~8 B1~B8 Switch Output B to 1~8 C1~C8 Switch Output C to 1~8 D1~D8 Switch Output D to 1~8 E1~E8 Switch Output E to 1~8 F1~F8 Switch Output F to 1~8 G1~G8 Switch Output G to 1~8 H1~H8... -
Page 13: Telnet Control
6.7 Telnet Control Before attempting to use the telnet control, please ensure that both the Matrix (via the 'LAN /CONTROL' port) and the PC/Laptop are connected to the active networks. To access the telnet control in Windows 7, click on the 'Start' menu and type "cmd"... - Page 14 Once in the command line interface (CLI) type "telnet", then the IP address of the unit you wish to and "23", then hit enter. Note: The IP address of the Matrix can be displayed on the device's LCM monitor by pressing the Menu button twice. This will bring us into the device which we wish to control.
-
Page 15: Web Gui Control
6.8 Web GUI Control On a PC/Laptop that is connected to the same active network as the Matrix, open a web browser and type device's IP address on the web address entry bar. The browser will display the device's status, control and User setting pages. - Page 16 Clicking on the 'User Setting' tab allows you to reset the IP conguration. The system will ask for a reboot of the device every time any of the settings are changed. The IP address needed to access the Web GUI control will also need to be changed accordingly on the web address entry bar.
-
Page 17: Connection Diagram
7. CONNECTION DIAGRAM Monitor Monitor Monitor Monitor Amplier Amplier Amplier Amplier Monitor Monitor Monitor Monitor Active Active Active Active Speakers Speakers Speakers Speakers IR In Network Router 8×8 DVI Matrix with Audio DVI OUT DC 24V DVI IN Power Supply Smartphone RS-232 or Tablet... -
Page 18: SpeciCations
8. SPECIFICATIONS Video Bandwidth 225MHz/6.75 Gbps Input Ports 8×DVI, 8×3.5mm Mini-jack, 1×IR, 1×RS- 232, 1×mini USB Type B (For rmware update only), 1×RJ-45 (CONTROL) Output Ports 8×DVI , 8×3.5mm Mini-jack ESD Protection Human-body Model: ±8 kV (air-gap discharge) ±4 kV (contact discharge) Power Supply 24 V/6.25 A DC (US/EU standards, CE/ FCC/UL certied) -
Page 19: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Digital Theater System Digital Visual Interface EDID Extended Display Identication Data HDCP High-bandwidth Digital Content Protection HDMI High-Denition Multimedia Interface HDTV High-Denition Television Liquid Crystal Monitor Universal Serial Bus Video Graphics Array WUXGA Wide Ultra Extended Graphics Array... - Page 20 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw 20120518 MPM-CMSI8D8DSA...
