Compal JHT01 Service Manual page 91

Contents
Chapter 5 Disassembly Guide
1. Disassembling the Base Unit .................................................................. 5-1
1.1 Removing the Battery Pack ...........................................................5-2
1.2 Removing the HDD Module ...........................................................5-3
1.3 Removing the DDR RAM...............................................................5-5
1.4 Disassembling the ODD (CD-ROM/DVD-ROM/CD-RW...) ...........5-7
1.5 Removing the Keyboard ................................................................5-9
1.6 Removing the Power Board.........................................................5-12
1.7 Removing the Modem card..........................................................5-13
1.8 Removing the System Fan ..........................................................5-16
1.9 Removing the Thermal Module....................................................5-17
1.10 Removing the CPU ......................................................................5-18
1.11 Removing the Bluetooth Module..................................................5-19
1.12 Removing the LCD Module..........................................................5-20
1.13 Disassembling the Display and the Inverter Board ......................5-22
1.14 Removing the Camera Module ....................................................5-26
1.15 Removing the Logic Upper ..........................................................5-27
1.16 Removing the Function Board .....................................................5-29
1.17 Removing the Motherboard .........................................................5-30
1.18 Removing the Modem cable card ................................................5-31
1.19 Removing the Touch Pad.............................................................5-32
