SCOPE

This document describes the functional specifications for the Compal Notebook
personal computer JHT01 series. The system is hardware and software
compatible with the IBM PC/ATX personal computer.
1.1

One 2.5" W, 9.5mm H Hard Disk, Up to 250GB

• Support SATA 3.0Gb/s
• 5400RPM or 7200RPM
• Easily removable
• Capacity from 80GB to 250GB and bigger in future
1.2

Optical Disc Drive

• 12.7mmh, Combo (DVD/CD-RW) Drive
• 12.7mmh, DVD Super Multi Drive
1.3

Touch Pad:

• Length: 84±0.2mm
• Width: 42±0.2mm
• PCB Thickness: 1.0±0.15mm
• MAX Thickness: 3.4±0.15mm
1.4

Keyboard

• Length: 300+0.05-0.30mm
• Width: 108.9+0.05-0.20mm
• Height: 5.10+0.3-0. 3mm
• Stroke: 2.5+0-0.3mm
1.5

Display Device

LCD
• COLOR TFT/WXGA LCD (CMO N141I3-L02 Glare)
Dimensions: 320.0 (W) x 206 (H) x 5.5 (D) mm (max)
1280 x 800 WXGA Resolution
Brightness: 220 (Type)
1-2
