JHT01 Service Manual
Offset Description
Full charge capacity
2Ch-2Dh
Gasgauge
2Eh
Battery cycle counter
2Fh
Battery current
30h-31h
Battery average current
32h-33h
System power consumption
34h
Battery Volt
35h
Battery Temp
36h
Battery Average Temp
37h
Battery charge current
38h-39h
Battery current Temp sample counter
3Ah
Battery Command index for read battery through SMBus
3Bh
Count up to communicate battery
3Ch
Count up if battery is arrived overtemp
3Dh
SMBus status
3Eh-3Fh
Battery over voltage counter
40h
Communication fail counter
41h
Battery voltage of ADC
42h
Cell1 voltage
43h-44h
Cell2 voltage
45h-46h
Cell3 voltage
47h-48h
Cell4 voltage
49h-4Ah
Battery staus1
50h
Bit0 - Battery exist
Bit1 - Battery full
Bit2 - Battery empty
Bit3 - Battery first in
Bit4-5 - reserved
Bit6 - Battery read complete
Bit7 - Use LI_ION or NI_MH#
Battery staus2
51h
Bit0 - Low battery
Bit1 - Check EDV1
Bit2 - Set EDV1
Bit3 - Battery shutdown 5%
Bit4 - Start to read battery
Bit5 - Start to count communication counter
2-42
