JHT01 Service Manual
Connect the AC adapter to the DC-IN socket
Is the DC-IN LED on?
Is the Battery LED on?
Turn the Power switch on
Is the Power On LED on?
Is the logo message display?
If the password message displays, type the
password, then press Enter
Is Windows being loaded?
6-2
START
Yes
Yes
Yes
Yes
Yes
Yes
Figure 6-1 Troubleshooting flowchart (1/2)
Perform the Power Supply
Troubleshooting procedures in
No
section 6-2
Perform the Power Supply
Troubleshooting procedures in
No
section 6-2
Perform the Power Supply
Troubleshooting procedures in
No
section 6-2
Perform the Display
No
Troubleshooting procedures in
section 6-3
Perform diagnostics program
No
