JHT01 Service Manual
To determine if the computer's built-in speakers are functioning properly,
perform the following procedures. Figure 6-9 outlines the process. First adjust the
speaker volume to an appropriate level. Start with Procedure 1 and continue as
instructed.
• Procedure 1:
• Procedure 2:
• Procedure 3:
• Procedure 4:
10.1 Procedure 1
Try different audio sources (e.g. an audio CD and digital music file) to determine
whether the fault is in the speaker system or not. If not all sources have sound
problems, the problem is in the source devices. If all have the same problem,
continue with Procedure 2.
10.2 Procedure 2
Connect a set if earphones or external speakers. If these function correctly, go to
Procedure 3. If they do not function correctly, the system board may be defective
or damaged. Replace it with a new one.
10.3 Procedure 3
Disassemble the computer following the steps described Replacement Procedures
and make sure the speaker cable is firmly connected to the system board. If the
stereo speakers are still not functioning properly, go to Procedure 4.
10.4 Procedure 4
If the stereo speakers don't sound properly, the stereo speakers may be defective
or damaged. Replace them with new ones. If the stereo speakers still do not work
properly.
6-24
Audio source test
Earphone test
Connection check
Replacement check
Audio source test
Earphone test
Connection check
Replacement Check
