JHT01 Service Manual
12.8.2 Definitions of System state LED
• Power LED and Suspend LED indicate the systems power states by their
combinations
• (Normal on is Blue / Blinking is Amber)
System Power
State
S0
S3
S4
S5/G3
The Power LED states blinking to indicate the system starts the process for
entering the S3 state and stop blinking and turns on when systems enters S3
state. On wake from S3, it blinking to indicate that system is waking up and
turns off when resume from S3 is completed
12.8.3 Definitions of AC LED (
• Please refer PDD document.
12.8.4 Definitions of HDD accessing state Blue LED (
• Please refer PDD document.
12.8.5 Definitions of Bluetooth state LED
• Please refer PDD document.
12.8.6 Definitions of Wireless State LED
• Please refer PDD document.
12.8.7 Definitions of Battery state LED (
• There is one dual-color LED indicator both of Blue and Amber color.
• LED colors and definition
• Blue color and Amber color defined for battery charging and discharging state.
The definition as below:
Battery State
Charging
Discharging
2-28
Power LED
On
Blinking
Off
Off
)
LED colors
Blue and blinking
(ON 1S, OFF 1S)
Blue solid on
Amber and blinking
(ON 500mS, OFF
500mS)
Blue color off
Amber color off
Suspend LED
Off
Off
Off
Off
)
)
Description
Battery charging with AC.
Battery full by AC charge and stop
charging.
Battery abnormal stop charging with
AC.
Abnormal stop charging: BadCell,
OverTemp, communication fail and
OVP.
Battery in discharge mode.
