12.16.4 Internal Key-Pad mode control
• The key pad mapping shows as below.
Single key

12.17 EC name space Configuration

12.17.1 Customer EC name space definition
Offset
Customer EC name space
00h - 07h
12.17.2 Project EC name space definition
Offset
Project EC name space
08h - 0Fh
12.17.3 SMBus EC interface ACPI RAM definition
Offset
SMBus protocol
60h
SMBus statue
61h
Bit0-Bit4 - Status
Bit5
Bit6
Bit7
SMBus Address
62h
SMBus Command
63h
SMBus Data
64h - 83h
SMBus BCNT
84h
Number lock on
7
8
9
*
4
5
6
-
1
2
3
+
0
,
.
/
- Reserved
- ALARM
- DONE
Number lock off
Description
Description
Description
JHT01 Service Manual
7
8
9
0
U
I
O
P
J
K
L
;
M
,
.
/
