JHT01 Service Manual
Offset Description
ACOFF_SOURCE: Enable AC_OFF signal
A5h
Bit0 - CHARGECURRENT (1 = AC_OFF for when stop charge but have charge current)
Bit1 - ADPOVP (1 = AC_OFF for adaptor improper)
Bit2 - BATTLEARN (1 = AC_OFF for battery at learning mode)
Bit3 - CMD (1 = AC_OFF for Command)
Bit4 - BATTOVP (1 = AC_OFF for battery OVP)
Bit5 - LEAKCURRENT (1 = AC_OFF for Leakage current)
Bit6 - AIRADAPTOR (1 = AC_OFF for air-adaptor)
Bit7 - ACOFF (Control AC_OFF active, 0: enable, 1: disable)
Reserved
A6h
OS Throttling Temp. For system read setting.
A7h
OS Shutdown Temp. For system read setting.
A8h
Throttling Temp put a temp in for system throttling.
A9h
For Tcontrol temp, sysbios will put Tcontrol temp
AAh
THERMAL_STATUS
ABh
Bit0 - MODE (0=Local mode, 1=Remote mode)
Bit1 - FANSPDB0 (Fan on/off parameter0)
Bit2 - FANSPDB1 (Fan on/off parameter1)
Bit 2 1 (When control by OS)
Bit3 - INITOK (0:Control by OS 1:Control by EC)
Bit4 - Fan1 Active
Bit5 - Fan2 Active
Bit6 - Fan speed timer init OK
Bit7 - SKINMODE
SHUTDOWNTEMP: Shutdown temperature
ACh
FAN_STATUS1: Just for utility (low nibble: Fan's speed step number; high nibble: Fan's
ADh
number)
THROTTLING_INDEX
AEh
Bit 0~5: Throttling level
0 = No throttling
1 = throttling 12.5%
2 = throttling 25%
8 = throttling 100%
Bit6 - THRM_SW (1=SW Throttling active)
Bit7 - THRM_PIN (Throttling status; 1=HW Throttling Pin active)
THROTTLING_SOURCE
AFh
Bit0 - TS_THERMAL (1: Throttling for thermal)
Bit1 - TS_BATTCAP (1: Throttling for capacity)
Bit2 - TS_BATTCOMMFAIL (1: Throttling for communication fail)
Bit3 - TS_PWRLOADING (1: Throttling for adaptor power loading protect)
Bit4 - TS_BATTTEMP (1: Throttling for battery over temperature)
2-38
0 0: Fan off
0 1: Fan on speed 1
1 0: Fan on speed 2
1 1: Fan on speed 3
0=skin address 90
1=skin address 92
.
