Camera; Keyboard - Compal JHT01 Service Manual

• COLOR TFT/WXGA LCD (CPT CLAA141WB05A Glare)
Dimensions: 320.0 (W) x 206 (H) x 5.5 (D) mm (max)
1280 x 800 WXGA Resolution
Brightness: 200 Nit (Type)
• COLOR TFT/WXGA LCD (LPL LP141WX3-TLN2 Glare)
Dimensions: 320.0 (W) x 206 (H) x 5.5 (D) mm (max)
1280 x 800 WXGA Resolution
Brightness: 200 Nit (Type)
1.6

Camera

• 1.3M CMOS module, fix-focus, camera module (Chicony, CNF7163)
• 2.0M CMOS module, fix-focus, camera module (Suyin)
• 2.0M CMOS module, fix-focus, camera module (Chicony CNF7247)
1.7

Keyboard

• 86 / 87 keys with 101/102 key emulation
• 2.5±0.15mm full stroke keys
• Phantom key auto detect
• Overlay numeric keypad
• Support independent pgdn/pgup/home/end keys
• Support reverse T cursor keys
• Factory-configurable different languages by OEM customer
• Window key supported
JHT01 Service Manual
1-3
