6. Parameter description

6.1. Direct numbers dial – memories
Parameter Value
1 tt nn...
tt – button number (memory), always has 2 digits [01-04]
nn – telephone number up to 24 digits to be stored. Refer to the table for other choices.
stored in parameter 1 is the number for the first group or the number for Day mode.
Parameter Value
2 tt nn...
tt – button number (memory), always has 2 digits [01-04]
nn – phone number up 24 digits to be stored. Refer to the table for other
choices.
Numbers saved in parameter 2 are numbers of second group, or numbers
Night mode.
Default settings doesn't erase as same as changed those saved numbers.
Note: The switchover to Day/Night mode remains set in the unit even after line disconnection.
For the Link Ana iDP, tt is always 01

6.2. Relay

Parameter Value Description
31 r m
r – relay number [1-2]
m – relay mode [1-8 for r=1 is not mode m=5]
Modes m=1,4,5,6 please see "4.3. Relays mode control."
m=1 mode relay – activated by command (internal code) or password (external code) 1 pulse for time
t1/t4 (using for electrical locks) or 2 pulses when is activated for time t1/t4, open for time t2/t5
and close for time t1/t4 (sliding door opening)
m=2 closed for time of line OFF HOOK (camera) – close when door intercom picks up and open by
hanging up
m=3 closed for time of line OFF HOOK and more for time t1/t4 after hang up (lighting) – closed when
door intercom picks up and stays closed for time t1/t4 after door intercom hangs up (for this time
line is busy, at version /C and C is after switching DIP 3,4 and settings Parameter 64 for time t1/t4
line hanged up)
m=4 mode button – closed when any button is pushed and open after time t1/t4 (usage for example:
connection external bell)
m=5 mode progressive opening – you can setup into this mode relay 2 only because relay 1 will be
setup automatically into mode m=1. By command (internal code) or password (external code) is
activated relay 1 for time t1, then is running time t3 before closing relay 2. Then is relay 2
activated for time t4 and then door intercom hangs up. When dialled command or password match
to 2 pulses then in sequence will appear two pulses separated by time t2/t5.
p.12 | 23
Description
nn=destination Number. tt=button
number
Description
nn=destination Number. tt=button
number (01)
Relay mode
Description
Default
-
Default
-
Description
Default
11
Dial
0 - 9 0 - 9
# #
* **
Flash * #
Pause * 0
T h e n u m
Dial
0 - 9 0 - 9
# #
* **
of
Flash * #
Pause * 0
