Linkcom Link Ana iDP Manual page 18

Parameter Value
503
504 mm
505
506
tt –
Time of tone duration DTMF (tone) dial is calculated up:
(Inserted number) x 10 = tone duration time [ms]
[range 04-16 correspond to 40-160ms]
m – Time of space duration between DTMF tones is calculated up:
(Inserted number) x 10 =pause duration time [ms]
[range 04-16 correspond to 40-160ms]
f – Time of Flash duration is calculated:
Inserted number x 100 = Flash duration time [ms]
[range 1-6 correspond to 100-600ms]
p – Time of pause duration is calculated:
Inserted number x 100 + 400 = pause duration time [ms]
[Range 1-0 correspond to 500-1400ms]
– Time p is also time of pause between numbers at pulse dialing
Parameter Value
507
uu – level of sending tone (DTMF) dial into line, range is -4 to -16dBm. You insert desired level, uu=04 is
-4dBm, uu=10 is -10dBm
Parameter Value
508
509
p – preemphase is rate between upper and lower groups of DTMF frequency. You can select rate 2,2
dB with p=0 (Europe) or rate 3,2dB with p=1 (Australia).
s – listening –in DTMF level you can select in four levels:
p.18 | 23
Description
Time of tone duration DTMF (tone) dial
tt
(04-16)
Time of space duration between DTMF
tone (04-16)
f Time of Flash duration (1-6)
Time of pause duration / pause between
p
numbers (1-0)
Description
Level of sending tone DTMF dial in
uu
[-dBm](04-16)
Description
preemphase preemphase DTMF
p
(0/1)
S Listening –in DTMF - level
Level of listening in DTMF
Default
10 (100ms)
10 (100ms)
1 (100ms)
4 (800ms)
Default
Default
(1-4)
s - dial
[dB]
-15 1
-9 2
-3 3
+3 4
10
0
2
