permitted number of digits is reached. For parameters 1 and 2 the maximum number of digits is 16, and
for parameters 32,33,34 it is 6.
If, during programming, you enter a number that is not allowable, then the unit immediately emits an
error tone. The parameter will not be recorded or changed, and the unit will return to its initial
programming state and it will be possible to repeat the parameter setting or program another
parameter.
The unit stays inactive in programming mode for 34 seconds and will then automatically hang up. Every
time a DTMF tone is dialed, this period is reset. Alternatively, parameter 9 may also be selected to end
programming mode.
To program a parameter, enter the parameter number followed by the value you wish to set. The unit
will either respond with the Parameter Confirmation Tone, or one of the Error Tones.
Note 1. if you wish to maintain the connection in programming mode (i.e. extend the 34 seconds
•
period) then it is necessary to occasionally press a key (e.g. *, # or 7). The unit will respond with
an error tone but the connection will be kept alive.
Note 2. The # sign is not used in the values for parameters 32,33 and 34, and can be used to
•
immediately save the parameter.
Note 3. If you hang up the phone during programming mode without press 9, the doorphone will
•
stay in programming mode during 30 seconds.
5.2 PC programming – "Link Analog Manager" software
To setup the unit from a PC you will require a special USB tool cable, available separately, and must first
install the USB driver and software. Refer to the www.linkcom.fr for more details. The unit must also be
connected to the telephone line.
Procedure:
Connect the Link Ana iDP to the phone line
•
Connect the unit to the PC with the special USB cable.
•
Run the software program. The unit will enter PC programming mode and emit the Enter
•
programming tone If connection is lost, it is necessary to disconnect the USB cable from unit
and connect it again. The unit will answer and, providing the program is running, it will confirm its
entry into programming mode again.
When the connection is correct, you can the firmware version of Link Ana iDP (visible in bar).
