Digital Output (DO)

The DO socket allows the IP camera to send output to an external device. While executing
the DO notification action, the IP camera drives voltage on the connected DO wire to the
triggering voltage level for X number of seconds. The connected external device will then
be triggered for X number of seconds.
Triggered Voltage Level - OPEN or GROUND
Users should select the option according to the specification of their external device.

Video Clip

This function is used to determine when video clips will be recorded and stored after an
event is triggered.
Pre-alarm buffer - Images can be stored internally on the server from the time
immediately preceding the trigger. Enter the desired length of time.
Post-alarm buffer - Images can be stored internally on the server from the time
immediately following the trigger. Enter the desired length of time.
Maximum buffer size –Specify the maximum file size allowed.
Click Apply to apply settings or Cancel to cancel changes.
68
