manually and move sufficiently close to the screen to observe the effects of the
adjustments.
Y/C Delay
Where Video signals are concerned, use this adjustment to correct horizontal color
misalignment within the projected image. For a given video standard (for example PAL
or NTSC) the stored value does not normally require further adjustment, unless the
source or connection cable is changed.
Signal Range
Determines the signal data range of HDMI signals. It is available when the HDMI signal
comes from a RGB source or when the AVI (Auxiliary Video Information) infoframe of
the HDMI signal is missing or inconsistent.
•Auto determines the signal range using the information provided by the AVI
infoframe of the HDMI signal. If the AVI infoframe is missing or incosistent, the
projector uses values 0-255. Auto (which is the default setting) usually selects the
correct signal range but you can force either 16-235 or 0-255
•16-235 sets black at R, G, B = 16 and white at R, G, B = 235, to match the luminance
values of digital component standards
•0-255 sets black at R, G, B = 0 and white at R, G, B = 255

Setup

This menu section provides access to installation adjustments.
Orientation
Selects the orientation of the projected image. Available settings are: Floor, Ceiling,
Floor Rear and Ceiling Rear.
Keystone
This adjustment compensates the distortion resulting from the angle of projection.
Note: Keystone may cause artifacts in the image and may not be available when
displaying specific 3D content (see Table 4.2). SIM2 recommends that you use this
feature only when necessary.
Projection Lens
To set the custom settings for zoom, focus, vertical and/or horizontal shift is necessary
to enter the SETUP menu, Projection Lens or more quickly by pressing the F1 button
on the remote control.
•Zoom: see zoom on page 33
•Focus: see focus on page 33
•Lens Shift: use ◂, ▸, ▴ or ▾ to shift horizontally and/or vertically the projected image
•Lens Center: auto lens adjustment to reach on-axis position.
•Vertical Picture offset: vertical compensation for the center shift of image (see note).
•Lens Shift Calibration: Perform calibration and return lens to the center position
•Lens Zoom-Focus Calibration: Perform zoom and focus motors calibration
There is the possibility to save the settings for the positions of zoom, focus, vertical
and/or horizontal shift corresponding to a video format for each type of signal, for
each input of the projector. (see "Memories" on page 34)
