Installation
Overview
1.
2.
3.
4.
Before starting, download and install the latest versions of the following software:
Global Configurator Plus and Global Configurator Professional — For setting
…
up and configuring the control processor and touchpanel.
GUI Designer — For designing layouts for Extron TouchLink Pro touchpanels and
…
third party touch interfaces.
See
Configuration Software
Obtain the following network information from your network administrator:
DHCP status (on or off). If Dynamic Host Configuration Protocol (DHCP) is off, you
…
will also require
IP address
…
Subnet mask
…
Gateway
…
User name — By default these are either admin or user.
…
Passwords — By default these are either extron (for admin) or the field is left blank
…
(for user).
MAC address — Make a note of the touchpanel Media Access Code (MAC)
…
address.
Mount and cable the units:
ATTENTION:
• Do not power on the touchpanels or control processors until you have read the
Attention notice on page 8
• Ne branchez pas les écrans tactiles ou les contrôleurs avant d'avoir lu les mises
en garde page 8 (source d'alimentation 12 VCC) ou
Mount the units. There are several mounting options for Touchlink Pro touchpanels
…
(see Mounting on page 19).
Connect cables to the touchpanels (see
…
Connections on page 6).
Connect the power cords and power on all devices (see
…
page 7 or Network and Power over Ethernet (PoE) Connector
Set up the Touchpanels for Network Communication:
Connect the PC that you will use for setup, the control processor, and the touchpanel
…
to the same Ethernet subnetwork.
Use the Setup Menu (see page 11) or the Toolbelt feature of Global Configurator Plus
…
and Global Configurator Professional to set the DHCP status and, if necessary, the IP
address, subnet mask, gateway address, and related settings for the touchpanel.
on page 16.
(12 VDC power supply) or on
page 10
TLP Pro 520M Rear Panel Features and
Power connector
TLP Pro 520M • Installation Overview
page 10 (PoE injector).
(injecteur PoE).
on
on page 9).
3
