5. WEB SOFTWARE
5.2
Screen Explanation
The screen is divide into several areas.
Menu bar
Sub menu area
Status area
The status area displays the reception signal level, ship position information, date and
time. Data is updated every 30 seconds.
5-2
Status area
Information area
Reception signal level (8 bars)
Ship latitude Ship longitude
Date
Administrator login/
logout password.
Refer to 5.9.1, 6.1.1
System message area
Time
