2) To search by date, enter part or all of the date in the [Date] field. If you are
searching by group name/session name, enter a part of the name in the
[Label] field. To search by connection, enter part or all of the connection name
in the [APN] field.
Matching search results appear below the Search bar.
Note: Select [Standard], [8 kbps], [16 kbps], [64kbps], [32kbps], [128kbps] or
[256kbps](FELCOM 500 only) from the [Service] listbox to view only the se-
lected service.
4. To arrange the log in ascending or descending order, do the following:
1) At the top of the log list, click either [Date], [Duration], [KBytes], [Service], [La-
bel], [APN], or [Code].
2) Click the item again to change between
der.
5. To save the log to a CSV file, click the [Save CSV] button. (See section 5.9.2 for
complete information.)
The Data connection log additionally records the latitude and longitude (at the
time communication ended), CN0 (RX signal level), Message (message only
shown when there is an event code).
Note 1: You can find the latitude and longitude at the time a call ended and RX signal
level by putting the cursor on the date on the Data connection log display. If there is
no data (old log, no GPS data) "--°--'--", ---°--'--" appears.
Note 2: You can show the details of an event code by clicking the event code on the
Data connection log display. Click the [Back] button to return to Data connection log
display.
5.9.5

How to view the Event log

To view the Event log do the following:
1. Click [Log] in the menu bar.
2. Click [Event log] to show the Event log. Corresponding to the message, the follow-
ing [Error], [Warning] or [Notice] indicator appears.
• Error: The problem affects the startup of the equipment .
• Warning: The problem limits the functionality of the equipment.
• Notice: Internal event (status). Not an indication of equipment trouble.
1) Time of event
3) Details of event 4) Event code
appears beside the selected item.
2) Location of event
5. WEB SOFTWARE
(ascending) or (descending) or-
5-27
