Entry screen/Edit screen
Entry screen
Item
Group
Action
Direction
DST. address
From address
Protocol
Add button
Save button
Cancel button
Description
Display group name
Select action (Ignore, Reject, Pass).
Show direction (WAN→LAN, LAN→WAN).
Enter, edit destination address (IPv4 address).
Enter, edit source address (IPv4 address).
Select protocol (ALL, ICMP, Any, TCP/UDP).
• If [Protocol] is [Any], displays the protocol number (1-
255).
• If [Protocol] is [TCP/UDP] only, select TCP/UDP,
TCP, UPD from list box. Enter port no. (range: 0-
65535).
Register entered information. The IP filter setting
screen appears.
Save entered information. The IP filter setting screen
appears.
Return to IP filter setting screen.
6. WEB FUNCTIONS
Edit screen
6-21
