6. WEB FUNCTIONS
6.1.2

How to display the Information screen

You can view information of GPS, Analog ports, Incoming Indicator, and Serial port in
the [Basic] submenu, LAN and PPPoE in the [Network Settings] submenu.
1. Click [Settings] in the menu bar. The Settings sub menu is displayed on the left
hand side.
2. When the Information screen is not displayed, click [Information] in the sub menu
to display the Information screen.
6.1.3

PBX (SIP Server) setting

How to set incoming route
Set primary (and secondary) terminal for Fax and external calls. Priority terminals will
ring first. If a call is not answered, secondary terminals will ring.
1. Click [Settings] in the menu bar.
2. Click [PBX settings].
3. Click [Incoming routing].
4. Click [Voice] or [FAX].
[Voice]: Adjust settings for incoming phone call.
[FAX]: Adjust settings for incoming Fax.
Internal line
5. Place a [ ] in the [1st. ring] check box of the terminal to ring first. Do not put a [ ]
if terminal is not to ring first.
6. Place a [ ] in the [2nd. ring] check box of the terminals to ring second.
7. Enter the ring duration time (1st ring duration time, 0-99 sec.).
Note: If set to 0 sec., [2nd ring] is turned off.
6-2
- For the handset, the name set in [PBX Settings]
[Extension] [Note] displays.
- For the telephone, the name set in [Basic settings]
[Analog ports] [Note] displays.
Set ring duration time
