General Tab - imagistics ipc1-im8130 Operator's Manual

Document Information Dialog Box Reference
The Document Information dialog box opens when you select a document
and click
about the document such as size, location, and status.
The Document Information dialog box contains two tabs.

General Tab

This tab presents general information about the document:
Name: the name of the document.
Location: where the document is stored.
Pages: the number of pages in the document.
Status: the condition of the document:
Note: The maximum size of image data you can send by e-mail
attachment is 20 MB. However, the administrator can specify a lower
limit in the range 2-20 MB if the e-mail client software is unable to
handle fragmentation successfully.
Created: the date and time when the document was scanned.
Protected: whether the document is password protected:
Pages Tab
This tab describes the configuration of the pages in the document:
Page: is the page number.
Image Size: is the number of pixels in the image on the page.
DPI: is the resolution of the image in dots per inch.
OK: returns to the Main TWAIN dialog box.
HELP: opens the online Help file.
ipc1-im8130 Scan Operator's Guide
Progress Area: Displays a visual representation of the status of
the process being performed.
Comment Area: While you are retrieving the document, this area
displays the number of pages. It also displays a warning when
free storage space is less than 20% (Windows NT operating
system only).
on the Main TWAIN dialog box. Use it to view details
Properties
or .
Ready Retrieving
or .
Yes No
53
