SYSTEM
SIG VERSION
DEF • MODEL GRADE L4/L3
OPT • MODEL TYPE
REM • W/B DESCRIPTION...
SYS • AGING MODE
STA • FACTORY...
• SIGNAL...
ENG
• MAINTENANCE ID
PVM-14L5/20L5/D14L5A/D20L5A
W/B DESCRIPTION
SYSTEM
1.3 SIG
DEF
E14 OPT
REM
SYS
STA
ENG
0
AGING MODE
SYSTEM
SIG VERSION
DEF
OPT
REM
SYS
STA
ENG
FACTORY
SYSTEM
SIG
DEF
OPT
REM
SYS
STA
ENG
SIGNAL
SYSTEM
SIG
DEF
OPT
REM
SYS
STA
ENG
• COL1 65
• COL2 93
All white screen
To return to the original screen,
press the button of the input selector
illuminating in orange.
1.3
• MODEL GRADE L4/L3
• MODEL TYPE E14
• W/B DESCRIPTION...
• AGING MODE
• FACTORY...
• SIGNAL...
• MAINTENANCE ID 0
LOAD...
•
• STANDARD...
1080/48I OFF
•
• 720/50P OFF
LOAD cannot be selected and remains
in the blue display unless the NVM data is valid.
In such a case, clear the NVM and
make the NVM data valid first.
However, if the default factory data is damaged,
or if the FACTORY SET process is not executed
after ROM is replaced, LOAD cannot be executed.
STANDARD returns the various setups
of the user menu to the default factory setting.
When OFF, 1080/48I is identified
as NO SYNC.
When OFF, 720/50P is identified
as NO SYNC.
