Interface (Ports & Jacks)

Ports and Jacks

Item
Card Reader
DC-In Jack
External Monitor Port
HDMI-Out Port
A
Headphone-Out Jack
Microphone-In Jack
A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
SD (Secure Digital) / Mini SD / SDHC / SDXC
Push the card into the slot and it will appear as a removable device.
Plug the supplied AC/DC adapter into this jack to power your computer.
This port allows you to connect an external monitor, or Flat Panel Display, to get dual video or
simultaneous display on the LCD and external monitor/FPD.
The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector interface for
transmitting uncompressed digital streams. This allows you to connect an external monitor, TV or Flat Panel
Display etc. as a display device by means of a HDMI cable. Note that HDMI carries both audio and video
signals (see "HDMI Audio Configuration" on page C -
Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.
Plug an external microphone in to this jack to record on your computer.
Description
MMC (MultiMedia Card) / RSMMC
33).
