Model TSTATD4272C Multi Stage 4+2, Humidity Control,
Light Activated
Follow the Installation Instructions before proceeding. Set the
thermostat mode to "OFF" prior to changing settings in setup
or restoring Factory Defaults.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
www.DaikinApplied.com
CAUTION
NOTICE
7-D P
ay rogrammable

Unit Components

Figure 13: Thermostat Front Panel
Figure 14: Thermostat Hidden Buttons
15
C D T
ommerCial igiTal
IM 1227 • MODELS DC THERMOSTATS
hermosTaTs
