during printing.
Implementation of this mode would degrade the throughput.

14.5.1.2.5 Detailed Discussions of Bit 5

LaserBase MF6530 / / LaserBase MF6540PL / LaserBase MF6550 / KaserBase MF6560PL / / LaserBase MF6580PL
Select whether to enable or disable silent mode. Select "Enable" to modify the registration loop amount and thus reduce noises or squeaks the registration rollers
produce after picking paper from the individual paper inlets.

14.5.1.2.6 Detailed Discussions of Bit 7

LaserBase MF6530 / / LaserBase MF6540PL / LaserBase MF6550 / KaserBase MF6560PL / / LaserBase MF6580PL
You can specify whether the pre-rotation is to be extended.
If white streaks appear in the image in the H/H environment, selecting "Set" extends the pre-rotation by five turns. During the extended period, the charge Vpp is
increased to prevent white streaks from occurring.

14.5.1.3 SSSW-SW15

14.5.1.3.1 List of Function

LaserBase MF6530 / / LaserBase MF6540PL / LaserBase MF6550 / KaserBase MF6560PL / / LaserBase MF6580PL

14.5.1.3.2 Detailed Discussions of Bit 2

LaserBase MF6530 / / LaserBase MF6540PL / LaserBase MF6550 / KaserBase MF6560PL / / LaserBase MF6580PL
You can specify whether split recording is to be enabled when text data such as a header and body text is recorded. Selecting "Set" may split text data when a small
paper size such as A5 is selected. In this case, a page may be split in the middle of a character string.

14.5.2 Numeric Parameter Settings (NUMERIC Param.)

14.5.2.1 Numeric Parameter Functional configuration

LaserBase MF6530 / / LaserBase MF6540PL / LaserBase MF6550 / KaserBase MF6560PL / / LaserBase MF6580PL
No.
01: - 30:
31:
32:
33:
34:
35:
36:
37: - 38:
39:
40:
41:
42:
43: - 50:
51:
52:
53:
54:
55:
56:
14.5.2.2 <031: Top registration adjustment (manual feed tray)>
LaserBase MF6530 / / LaserBase MF6540PL / LaserBase MF6550 / KaserBase MF6560PL / / LaserBase MF6580PL
Adjust the top registration margin of paper picked from a manual feed tray. The larger the adjustment value, the wider the top margin of the image becomes.
Download Free Service Manual And Resetter Printer at http://printer1.blogspot.com
Bit Function
0 Not used
1 Not used
2 Not used
3 IFAX Permission of split recording of text data
4 Not used
5 Not used
6 Not used
7 Not used
Function
Not used
Top registration adjustment (manual feed tray)
Top registration adjustment (cassette)
Top registration adjustment (duplex unit)
Left-end registration adjustment (manual feed tray)
Left-end registration adjustment (cassette)
Left-end registration adjustment (option cassette)
Not used
Left-end registration adjustment (duplex unit)
Target fixing temperature adjustment (multi)
Target fixing temperature adjustment (cassette)
Target fixing temperature adjustment (option cassette)
Not used
Two-sided curl reform mode
Not used
Adjustment of margin at leading edge of copy
Adjustment of margin at trailing edge of copy
Adjustment of margin at right edge of copy
Adjustment of margin at left edge of copy
T-14-18
1
-
-
-
Enable
-
-
-
-
Default
50
50
50
100
100
100
100
6
6
6
3
0
50
0
0
0
-
-
-
Disable
-
-
-
-
Setting range
0 to 100, one unit = 0.1 mm
0 to 100, one unit = 0.1 mm
0 to 100, one unit = 0.1 mm
0 to 200, one unit = 0.1 mm
0 to 200, one unit = 0.1 mm
0 to 200, one unit = 0.1 mm
0 to 200, one unit = 0.1 mm
0 to 4, one unit = 5 deg C
0 to 4, one unit = 5 deg C
0 to 4, one unit = 5 deg C
0 to 6
0 to 9999, one unit = 5 deg C
0 to 9999, one unit = 5 deg C
0 to 9999, one unit = 5 deg C
0 to 9999, one unit = 5 deg C
Chapter 14
0012-7581
0012-7584
0011-7100
0011-7102
0011-4196
0011-4197
14-11
