Now, please install the SATA Hard Drive step by step:
1.
Align the mounting holes of the drive bay with the
mounting studs on the chassis. Use the provided
mounting screws to secure the drive bay in place.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Mounting Screw
31
Locate the SATA data connector on the SATA drive, and
2.
connect one end of the SATA data cable to the SATA drive
and the other end to the board.
SATA Data Cable
NSA 3130 User Manual
