Jumpers

RTC Clear (JP7)

Connector type: 1x3 3-pin header, 2.54 mm pitch
1
JP7
2
3
Pin Setting Pin Definition
1-2 On Normal
2-3 On CMOS Clear
1-2 ON Default

AT/ATX Mode Selector (JP4)

Connector type: 1x3 3-pin header, 2.54 mm pitch
1
3 2
JP4
Pin Setting
1-2 On ATX Mode
2-3 On AT Mode
2-3 ON Default
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
1 NC
2 ICH_RTCRST_N
3 Battery GND
Pin Definition
1 3VSB
2 AT_ATX_Select
3 GND

Console Type Selector (JP6)

Connector type: 1x3 3-pin header, 2.54 mm pitch
3 2 1
JP6
Pin Setting
1-2 On RTS to CTS
2-3 On Normal
2-3 ON Default

ME Force Update Pin Header (JP5)

Connector type: 1x3 3-pin header, 2.54 mm pitch
3 2 1
JP5
Pin Setting
1-2 On
2-3 On
2-3 ON Default
9
Pin Definition
1 SP_RTS1_R
2 SP_CTS1_R
3 SP_CTS1_CON
Pin Definition
1 NC
2 GPIO24
3 GND
NSA 3130 User Manual
