The gold mark on the CPU must align with pin 1 of the
7.
CPU socket.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Insert the CPU into the socket until it is seated in place.
8.
The CPU will fit in only one orientation and can easily be
inserted without exerting any force.
Do not force the CPU into the socket. Forcing
the CPU into the socket may bend the pins and
damage the CPU.
24
NSA 3130 User Manual
