Isolated GPIO Connector
Connector size: DSUB-9 pin
Connector location: COM1
5
1
6 9
Connector pin definition (VTC 6200)
Pin Description
1 Isolated GIN1
3 Isolated GIN3
5 Isolated GOUT4
7 Isolated GOUT3
9 Isolated GOUT1
Connector pin definition (VTC 6200-NI, VTC 6200-NI-DK)
PIn Definition
1 GIN1
3 GIN3
5 GOUT4
7 GOUT2
9 GND
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
Pin Description
2 Isolated GIN2
4 Isolated GIN4
6 Isolated GND
8 Isolated GOUT2
Pin Definition
2 GIN2
4 GIN4
6 GOUT1
8 GOUT3
10 GND
VGA Port x2 (Clone Mode)
The DB15 VGA port supports resolutions up to 1600x1200 @ 85 Hz,
2048x1536 @ 60Hz.
USB Port x 2
The two USB ports are compliant with USB 2.0 specifications.
LAN Port
The LAN port is an RJ45 interface with integrated LEDs and supports
10/100/1000Mbps Ethernet data transfer rates.
Audio Jacks (MIC-IN and LINE-OUT)
• MIC-IN jack receives monophonic input from an external microphone.
• LINE-OUT jack is the stereo output for connecting external speakers.
Odometer Sensor Connector (for VTC 6200-NI-DK)
Connector size: DSUB-9 PIN
Connector location
1 5
6 9
PIn Definition
1 DIR_N
2 DIR_P
3 NC
4 PULSE_P
5 PULSE_N
Note: Please refer to Appendix E for the pin definition information
of GPS with dead reckoning feature.
12
Pin Definition
6 GND
7 NC
8 NC
9 GND
