Package Contents

Before continuing, verify that the VTC 6200 / 6200-NI package that you received is complete. Your VTC 6200 / 6200-NI package should have all the items
listed in the following table.
Item P/N
1 4NCPM00302X00 POWER CON 3P PHOENIX CONTACT
2 5060100017X00 DAMPER
I HEAD BOLTS SCREW LONG
3 50311F0119X00
4 60233PW134X00 (N)POWER CABLE FOR VTK33B SMBUS SIGNAL
5 60233ATA20X00 SATA CABLE
6 60233PW102X00 SATA POWER CABLE
7 5042220027X00 (N)WIRE MOUNT
8 50311F0150X00 (N)F HEAD SCREW LONG
9 60233SAM05X00 GPS ANTENNA
10 50311F0100X00 ROUND HEAD SCREW W/SPRING+FLAT WASHER LONG P3x6 iso/SW6x0.5 NI
11 5043330316X00/ HDD BASE PLATE FOR VTC6200/ or HDD BASE PLATE
or 5043330354X00 FOR VTC6200-NI
12 5043330317X00 HDD BRACKET FOR CUSHION LEFT
13 5043330245X00 HDD BRACKET FOR CUSHION RIGHT
14 50344C0042X00 COPPER POST LONG
15 5060100012X00 HIGH-END DAMPER INSIDE
I HEAD BOLTS SCREW LONG
16 50311F0107X00
17 CD driver
