Rackmount Brackets - Nexcom VTC 6200 User Manual

Chapter 3: System Setup
The rackmount brackets provide a convenient and economical way of
mounting the system on the wall.
1. The mounting holes are located at the bottom of the system. Secure
the brackets on each side of the system using the provided mounting
screws.
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
2. Now mount the system on the wall by fastening screws through the
bracket's mounting holes.
Secure the
bracket to
the system
Rackmount
bracket
54
Fasten screws to mount the
system to the wall
VTC 6200 / VTC 6200-NI / VTC 6200-NI-DK User Manual
