COOLING SYSTEM
INSTALLATION
Install the radiator assembly by aligning its grommet with
the frame boss.
Install the collars and mounting bolts.
Install the upper radiator hose and tighten the band screw
securely.
Install the lower radiator hose and tighten the band screw
securely.
Connect the siphon tube.
Connect the fan motor 3P connector,
Fill and bleed the cooling systemlpage 6-5).
Install the following:
-
left middle cowl (page
2-4)
-fuel tank (page 5-3)
6-1
I
