Panel Operation

There are 3 states of operation: Online, Offline and Power On.
In the Online state, the keys provide the following functions: Go to Tear Off position, Line Feed/Form feed,
Load/Eject, and switch to Offline state.
In the Offine state, the keys provide the following functions: Font select, Pitch select, Line Feed/Form feed,
Load/Eject, and switch to Online state, micro feed, control PE (paper error) sensitivity, clear buffer and restore
factory defaults.
To enter the Power On state, the user holds down a key or a combination of keys while powering up the printer.
This state provides the following functions: Main Menu setup, Hex-dump, print Main Menu, access Service
Menu, adjust page margins, restore factory defaults, and firmware update.
The followings describe the 3 states in details.
Legend:
[A] = press and hold switch A
{B} = press and then release switch B
[A]+ {B} = press switch B while holding A
