5. Printer Setting Changes

In order to meet individual print requirements, the printer configurations may be changed as follows: Hold down
the Tear Off key while powering on the printer, release the Tear Off key when the print head starts to move. The
printer will enter Main Menu setup state. Follow the instructions printed on how to make setting changes. When
a new setting is saved, it is retained after the printer has been powered off.
The Main Menu is grouped into 5 sub-menus: System Setup, Page Setup, Print Setup, Interface Setup and
Advanced Setup. A detailed description of the sub-menus is given below. The settings in bold and italic refer to
the default settings.

System Setup

System
Valid Settings
Setup
ESC/P2, IBM 2390
Emulation
Plus
Auto CR
Yes, No
(IBM)
Auto LF Yes, No
Bi-Dir, Uni-Dir,
Print Dir
Auto
Top Print
Bi-Dir, Uni-Dir
Dir
Impact Normal, Heavy
IBM AGM Yes, No

Print Setup

Print Setup
Font (Others) OCR-B, OCR-A, ORATOR, GOTHIC, SOUVENIR
Pitch 10cpi, 12cpi, 15cpi, 17cpi, 20cpi, PS
Zero 0,Ø
Selects the printer emulation. This should be the same as the host
printer driver.
Yes: LF = LF+CR; No: LF = LF
(Applies to IBM emulation only)
Yes: CR = CR+LF; No: CR = CR
Auto: Text & graphics in bi-direction; double height in uni-direction.
Uni-Dir: Prints everything in uni-direction. Bi-dir: Prints everything in
bi-direction. Note: Top position print direction may be affected by Top
Print Dir setting.
Bi-dir: Prints top position according to Print Dir setting. Uni-dir: Prints
top position in uni-direction regardless of Print Dir setting.
Heavy: Higher impact force for multipart printing
Selects the IBM graphic mode. Applies to IBM emulation only
Valid Settings
21
Function
Function
When Font is set to "Others"
on control panel, OCR-B,
OCR-A, ORATOR, GOTHIC
fonts are selectable.
Controls the characters per
inch setting.
Selects slashed or no-slash
zero.
