To load new roll paper in the printer at this point, see "Loading Rolls in the Printer."
Note

Removing the Roll Holder from Rolls

Removing the Roll Holder from Rolls

1
Lift the Holder Stopper lever (a) from the shaft side to
unlock it. Holding the Holder Stopper at the position
indicated (b), remove it from the Roll Holder.
2
Remove the Roll Holder from the roll.
3
When removing attachments, push the tips (a) in as you remove the attachment.
• 3-Inch Paper Core Attachment R (Roll Holder side)
User's Guide
Removing the Roll Holder from Rolls
P.322
➔
