Tail Landing Gear; Main Landing Gear - THE WORLD MODELS Groovy 90 Instruction Manual

Vertical Fin & Rudder
4
A A'
A = A'
5

Tail Landing Gear

Screw
PA3 x 12mm
4
Collar
2.6mm
1
6

Main Landing Gear

Screw
PM3x15mm
6
Screw
PM4x35mm
2
Screw
PA3 x 10mm
2
Collar
4.1mm
2
Washer
d3xD7mm
2
Washer
d4xD9mm
2
Washer
d3xD12mm
6
Nut
M4
1.5mm 2.5mm
Bottom View
Front
PM3x15mm
d3x D12mm Washer
Bottom View
P . 4
Apply instant type CA glue to both
sides of each hinge.
COMPLETED
PA3 x 12mm
M3 x 3mm Set Screw
PM4x35mm
d3xD7mm
Washer
M4 Nut
PA3x10mm
Wheel Ø55mm
2.6mm Collar
M3 x 3mm Set Screw
d4xD9mm
Washer
4.1mm
Collar
