Tail Landing Gear; Main Landing Gear - THE WORLD MODELS 1/3 Clipped Wing Cub Instruction Manual

6

Tail Landing Gear

PA 3.5x16mm Screw
3
PWA 2 . 5x12mm Screw
3
Bottom View

Main Landing Gear

7
PM4x30mm Screw
2
PA 3x14mm Screw
12
PA 4x25mm Screw
2
d4 x D12mm Washer
2
d4 x D9mm Washer
2
8 Landing Gear
3mmSet Screw
4
PA1.7X8mm Screw
6
D6.1mm Collar
4
PM 3x12mm Screw
8
d3xD7mm Washer
16
M3 Nut
8
COPPER PLATE
1.5x10x60mm
1.5mm
ALU.PLATE
3x15x77mm
2.5mm
Front
Bottom View
P.5
PA3.5 x16mm
M3x3mm
Set Screw
2.5mm
PM4x30mm
PA4x25mm
d4xD12mm
Washer
PA3x14mm
Front
Bottom View
Spring
PWA2.5 x 12mm
1.5mm
d4xD9mm
Washer
M3 Nut
coper plate
0.5x12x20mm
d3xD7mm
Washer
PM2x14mm
M3x3mm
M3x3mm
Set Screw
Set Screw
PA1.7mmx8mm
Collar
