0.46 Cubic inch displacement 2-stroke
0.70-0.81 Cubic inch displacement 4-stroke
Requires : 5-channel radio w/5 standard servos
Wing Span
Wing Area
Flying Weight
Fuselage Length
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
and 1 low profile retract servo.
INSTRUCTION MANUAL
57 in / 1450 mm
564 sq in / 36.4 sq dm
6.3 lbs / 2860 g
49 in / 1240 mm
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
Advertisement
Table of Contents
Related Manuals for THE WORLD MODELS P-40 Warhawk
Summary of Contents for THE WORLD MODELS P-40 Warhawk
- Page 1 57 in / 1450 mm Wing Area 564 sq in / 36.4 sq dm Flying Weight 6.3 lbs / 2860 g Fuselage Length 49 in / 1240 mm FACTORY PRE-FABRICATED The World Models Manufacturing Co., LTD. ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA www.theworldmodels.com...
-
Page 2: Before You Begin
I N D E X BEFORE YOU BEGIN P. 1 P. 2 PARTS LIST ASSEMBLY P.3-P.11 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. - Page 3 Parts List 12. LINKAGE CONNECTOR 2.1mm -- 1 set 1. MAIN WING -- 1 pair 2. SERVO MOUNTING PANEL (PL5310000) -- 1 pair 13. THROTTLE PUSHWIRE Ø1.2x440mm -- 1 pc. SCREW PB2x16mm -- 6 pcs PLASTIC TUBE d2xd3x300mm -- 1 pc. SCREW PWA2x8mm -- 8 pcs SOCKET HEAD SCREW M3.5x30mm -- 4 pcs TRI-HORN M3x14mm(L) -- 2 sets...
-
Page 4: Aileron Servo
Main Wing KA3x14mm Main Landing Gear Pre-installed Pre-glued Bottom View Ø1mm pilot holes for World Models tri-horn are pre-drilled. Please look for pin-hole Aileron Servo marks at under side of control surfaces. Fuel Tube PWA 2 x 8mm Straper 1.5mm Ø... -
Page 5: Retract Servo
Retract Servo PUSHROD TRAVEL 21mm R-side L-side Wheels up position Wheels down Position Lead to flap & Aileron servo Covering Film Covering Film 32x42mm 32x42mm Bottom View Stabilizer & Elevator Pre-glued (Stabi l i zer) (Mai n Wi ng) B=B' A=A' Temporary install the main wing, adjust leveling of the stabilizer to make it as parallel to the main wing as possible... -
Page 6: Tail Landing Gear
Vertical Fin & Rudder Pre-glued C=C' Completed Tail Landing Gear PA3x12mm Screw PM2x10mm Screw 1.5mm PA3x12mm M2 Nut 2.1mm Collar 3mm Set Screw 3mm Set Screw M2 NUT PM2x10mm Bottom View... -
Page 7: Elevator Pushrod
Elevator Pushrod Ø1m m pilot holes for Wor ld Models tr i-hor n ar e pr e-dr illed. Please look for pin-hole m ar ks at under side of contr ol sur faces. PB2x14mm Screw P B2 x14mm Cl e vi s 50mm 130mm Fuel Tube... -
Page 8: Fuel Tank
Fuel Tank Fuel Tank Setup 320cc Fuel Tank 320cc Fuel Tank 320cc Install Balsa 8x8x104mm (For Fuel Tank Position Fixing) Servo Set 3x3mm Set Screw 3x 3mm Set Screw Linkage Connector Throttle Pushwire M2 Nut Washer 2mm Washer 1.5mm Washer Throttle Servo M2 Nut Please refer to the attached sheet for linkage connector installation. - Page 9 Engine M3.5x30mm Socket Head Screw d3.5xD8mm Washer M3.5 Nut Installed Engine Position 130mm 5.12in d3.5xD8 Washer M3.5x30mm Socket Head Screw Plastic Tube Throttle Pushwire M3.5 Nut d2xD3x300mm Ø1.2x440mm Cowling Please refer to the attached sheet for usage of the transparent PWA2.6x12mm Screw 3D template.
-
Page 10: Radio Equipment
Canopy First insert the grommet to the canopy then apply screw. PWA2.3x12mm Screw d1.5xD6.5mm Silicon Grommet Decals Pilot Apply double-sided tape Silicom Grommet PWA2.3x12mm d1.5xD6.5mm Radio Equipment Install and arrange the servo as shown in the diagram. Elevator Pushrod J1(Pushrod Ø1.8x70mm) Ø1.8x70mm Pushrod Connector M2 Nut... - Page 11 Main Wing M4x35mm Socket Head Screw PWA3x12mm Screw d4x15mm Washer Socket Head Screw Washer M4x35mm d4xD15mm Bottom View 1.5mm PWA3x12mm Air Scoop Bottom View Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A=A' B=B' C=C' D=D' P.10...
-
Page 12: Control Throws
Control Throws Adjust the control throws as shown in the diagram. These throws are good for general flying. You can adjust according to your personal preference. Elevator 20mm 20mm Rudder 30mm 30mm Aileron 10mm 10mm C.G. The ideal C.G. position is 80mm ( 3.15 in ) behind the leading edge measured at where the wing meets the fuselage. - Page 13 Warning! I m portant S afety P recauti ons F irst tim e flyer sh o u ld n ever fly b y h im self / h erself. Assistan ce fro m exp erien ced flyer is ab so lu tely n ecessary. Pre - flig h t ad ju stm en t m u st b e d o n e b efo re flyin g , it is very d an g ero u s to fly a b ad ly pre - ad ju sted aircraft.
- Page 14 Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
-
Page 15: Optional Parts ( Accessories)
Optional Parts ACCESSORIES) 180mm Extension Fuel Filler Code No. Size Package Code No. Size Package KW0011800 PL8110030 180mm 1 set 15 x 22 x 49mm 1 x 1 pc 180mm Y-Cord Code No. Size Package KW0021800 180mm 1 pc Clevis Wrench Code No. - Page 16 Ｐａｔｔｅｒｎ Ｄｕｃｔｅｄ Ｆａｎ Ｆｕｎｆｌｙ Ｗａｒｂｉｒｄｓ Ｓｃａｌｅ Ｅｌｅｃｔｒｉｃ Ｓｐｏｒｔｓ Ｇｌｉｄｅｒ Ｂｏａｔ Ｔｒａｉｎｅｒ Ａｃｃｅｓｓｏｒｉｅｓ Ｃｏｖｅｒｉｎｇ （Ｌｉｇｈｔｅｘ ／ Ｔｏｕｇｈｌｏｎ） The World Models Manufacturing Co., LTD. www.theworldmodels.com A079SPO19990904...
